Grand Squares Study
The Grand Square is the densest of the classical figures and correspondingly rare, and the Grand Squares study gives you the windows in which one is fully formed. It generates an event each time four transiting bodies form a Grand Square, each opposing one of the others and squaring the remaining two, within orb.
Each event records all four bodies, their positions at the moment the figure closes, and the separation between each adjacent pair.
Create a Grand Squares Study
To add a Grand Squares study to the current workspace:
- Click Mundane Studies → Aspect Patterns on the menu bar.
- Click Grand Squares in the Aspect Patterns submenu.
Alternatively, click the Aspect Patterns drop-down button on the toolbar and select Grand Squares from its flyout.
The new study appears at the bottom of the Studies list and is selected automatically, so its settings open immediately. It takes its name from the study type.
What This Study Finds
An event is generated when each of four transiting bodies opposes one of the other bodies and squares the other two, forming a geometric square on the zodiac. Every contact in the figure is judged against the Aspect Orb, so the orb setting controls how tightly the square has to close before an event is generated.
Bodies are drawn from four lists, and the study tests one body from each. The Aspect Orb is one of the shared Orb Settings that several studies carry.
The settings column holds the Study Name, the ephemeris settings, the study date range and the Aspect Orb field, and beneath them two tabs. Inner Bodies holds the Inner Bodies and Inner-Mid Bodies selection lists, and Outer Bodies holds the Outer-Mid Bodies and Outer Bodies selection lists.
Events Table Columns
The events table lists one row per figure. Several columns are hidden by default, as the table notes. Right-click any column header to show or hide a column, as described in Choose Events Table Columns. The coordinate columns follow the study's Reference Plane: their headers read Longitude and Latitude in the ecliptic plane, and Right Asc and Declination in the equatorial plane. The table below gives the ecliptic-plane headers.
| Column | Description |
|---|---|
| Date Time | Date and time the figure perfects, in the application's long date and time format. Always the first column, and it cannot be moved. Visible by default. |
| Body1 | Name of the first body in the figure. Visible by default. |
| Body1 Longitude | The first body's primary coordinate, in degrees. Hidden by default. |
| Body1 Sign | The first body's position as degrees, sign and minutes of the zodiac. Visible by default. |
| Body1 Latitude | The first body's secondary coordinate, in degrees. Hidden by default. |
| Body1 Distance | The first body's radial distance, in astronomical units (AU). Hidden by default. |
| Body1 Speed | The first body's speed, in degrees per day. Hidden by default. |
| Separation Body(1-2) | Angular separation between the first and second bodies, in degrees. Visible by default. |
| Body2 | Name of the second body in the figure. Visible by default. |
| Body2 Longitude | The second body's primary coordinate, in degrees. Hidden by default. |
| Body2 Sign | The second body's position as degrees, sign and minutes of the zodiac. Visible by default. |
| Body2 Latitude | The second body's secondary coordinate, in degrees. Hidden by default. |
| Body2 Distance | The second body's radial distance, in astronomical units (AU). Hidden by default. |
| Body2 Speed | The second body's speed, in degrees per day. Hidden by default. |
| Separation Body(2-3) | Angular separation between the second and third bodies, in degrees. Visible by default. |
| Body3 | Name of the third body in the figure. Visible by default. |
| Body3 Longitude | The third body's primary coordinate, in degrees. Hidden by default. |
| Body3 Sign | The third body's position as degrees, sign and minutes of the zodiac. Visible by default. |
| Body3 Latitude | The third body's secondary coordinate, in degrees. Hidden by default. |
| Body3 Distance | The third body's radial distance, in astronomical units (AU). Hidden by default. |
| Body3 Speed | The third body's speed, in degrees per day. Hidden by default. |
| Separation Body(3-4) | Angular separation between the third and fourth bodies, in degrees. Visible by default. |
| Body4 | Name of the fourth body in the figure. Visible by default. |
| Body4 Longitude | The fourth body's primary coordinate, in degrees. Hidden by default. |
| Body4 Sign | The fourth body's position as degrees, sign and minutes of the zodiac. Visible by default. |
| Body4 Latitude | The fourth body's secondary coordinate, in degrees. Hidden by default. |
| Body4 Distance | The fourth body's radial distance, in astronomical units (AU). Hidden by default. |
| Body4 Speed | The fourth body's speed, in degrees per day. Hidden by default. |
| Separation Body(4-1) | Angular separation between the fourth and first bodies, in degrees. Visible by default. |
| Event Interval | Elapsed time since the previous event in the list. Hidden by default. |
